Cross Coil and Single Coil Razor Wire for High-Security Fencing

Anping County Xingpeng Hardware Co., Ltd. is an exporter and manufacturer of razor wire used for perimeter security in military sites, prisons, borders, airports, factories, and private properties. Common classifications include single coil razor wire, cross coil razor wire, flat wrap razor wire, and welded razor wire mesh, available in galvanized steel or stainless steel materials, with various blade profiles and diameters to meet different security levels and installation requirements.

Specifications

• Material: Galvanized steel, stainless steel 304/316
• Wire Diameter: 2.0 mm – 3.5 mm
• Blade Thickness: 0.5 mm – 0.6 mm
• Blade Length: 10 mm – 65 mm (commonly BTO-10, BTO-22, BTO-30, CBT-60, CBT-65)
• Coil Diameter: 300 mm, 450 mm, 500 mm, 600 mm, 750 mm, 900 mm, 980 mm
• Coil Length (Expanded): 8 m – 15 m (depending on coil type)
• Types: Single coil, cross coil, flat wrap, welded razor wire mesh
• Surface Treatment: Hot-dip galvanized, electro-galvanized, stainless steel polished
• Packaging: Coil wrapped in waterproof paper and woven bag or palletized

Applications

• Perimeter Security: Military bases, prisons, border protection
• Industrial Protection: Airports, power stations, factories, warehouses
• Residential Security: Private properties, gated communities, farms
• Temporary Barriers: Construction sites, event security zones
• Infrastructure Protection: Railways, highways, ports


Reference Number	Blade Style	Thickness	Wire Dia	Barb Length	Barb Width	Barb spacing
BTO-12		0.5±0.05	2.5±0.1	12±1	15±1	26±1
BTO-18		0.5±0.05	2.5±0.1	18±1	15±1	33±1
BTO-22		0.5±0.05	2.5±0.1	22±1	15±1	34±1
BTO-28		0.5±0.05	2.5	28	15	45±1
BTO-30		0.5±0.05	2.5	30	18	45±1
CBT-60		0.6±0.05	2.5±0.1	60±2	32±1	100±2
CBT-65		0.6±0.05	2.5±0.1	65±2	21±1	100±2
Barbed Tape Concertina (CBT);Barbed Tape Obstacle (BTO) Standard materials are either galvanized or stainless steel. Standard packages products are shown in the tables above, special specifications available on request.
